Solving Nanotechnology Application Challenges
High-pressure homogenization for nanoemulsions, particle size reduction and cell disruption, from laboratory development to production.
Microfluidizer® Processors
A Microfluidizer® processor is a high-pressure homogenizer used to produce nanoemulsions, reduce particle size and disrupt cells. It applies controlled shear and impact forces to liquid formulations to help create consistent particle size distributions from laboratory development through production.
No other high-pressure processor is capable of generating the shear levels routinely achieved by our Microfluidizer® technology.
Our machines consistently achieve superior results — significantly greater particle size reductions and remarkably uniform particle size distributions. If you depend on nanotechnology for innovative products with unprecedented properties — and undeniable advantages over your competition — count on Microfluidics for high-pressure homogenizers that are leading the global nano-revolution.
How Microfluidizer® technology works
A constant-pressure pumping system drives material through a fixed-geometry Interaction Chamber™. Inside the chamber, microchannels expose the fluid to controlled shear and impact forces. This ensures all of our Microfluidizer® Processors process every mL of material with the same high shear treatment, whether you’re processing a 1 mL batch or thousands of liters per hour.
Applications and particle size control
Microfluidizer® processors are used for nanoemulsions, liposomes, dispersions and cell disruption. The choice of Interaction Chamber™ geometry and processing conditions depends on the formulation and the target particle size distribution or cell-lysis outcome.
From lab-scale testing to production
The product range includes LM10 and LM20 laboratory processors, M110EH and M815 pilot-scale processors, and the M700 Series for production. Parallel microchannels increase throughput while maintaining the fixed-geometry processing approach used in laboratory development.
Testimonials
Discover why businesses choose to work with us
Prof. Thomas Schwartz
Massachusetts Institute of Technology (MIT) (USA)
Dr. Sven Hennig Associate Professor Structure Chemical Biology - Head of X-ray Crystallography
Vrije Universiteit Amsterdam, Netherlands
I would recommend the LM20 Microfluidizer as an essential tool for cell disruption.”
James Wright, Protein Scientist
Abcam Plc, UK
Johannes Raff, Ph.D.
The Institute of Radiochemistry at Forschungszentrum Rossendorf, Germany
"We have been working with Microfluidics for well over a decade and have multiple microfluidizers. Their technical service team is top-notch and we have complete trust and confidence in them. They always go out of their way to provide us with prompt phone and email technical support as well as fast turnaround times for on-site service visits. The technical service team is extremely knowledgeable, highly capable and very friendly.
We look forward to continuing our business relationship with Microfluidics well into the future."
Jean Alamed, Technical Assistant III
University of Massachusetts Amherst, Department of Food Science
